一种航模飞机用保护装置的制作方法

发布时间:2023-02-17 来源:http://www.quanyimoxing.com/

根据本实用新型的航模飞机,在现有的大型飞机模型基础上进行改进,将原本置于机身前端的螺旋桨放置在机身后端,可以避免或者减小拉力的损失,并且使得机身在飞行过程中更加平稳,提高了航模飞机的飞行效率和稳定性。另外通过螺旋桨弹性限位装置操作实现螺旋桨的启动和制动十分方便安全。
According to the model aircraft of the utility model, the existing large aircraft model is improved. The propeller originally placed in the front of the fuselage is placed in the rear of the fuselage, which can avoid or reduce the loss of tension, and make the fuselage more stable in the flight process, improving the flight efficiency and stability of the model aircraft. In addition, it is very convenient and safe to start and brake the propeller through the operation of the elastic limit device of the propeller.
提供一种航模飞机用保护装置,能避免参观者与航模飞机直接接触,不会发生参观者将航模飞机拿起进行参观的现象,避免造成的不必要的损失,有效保护航模飞机,同时在运输过程中能有效进行减振,避免航模飞机受到较大的振动力效果,不会造成航模飞机内部的零件松动,有效保护航模飞机,提高航模飞机的使用寿命。
Provide a protective device for the model aircraft, which can avoid direct contact between visitors and the model aircraft, avoid the phenomenon that visitors pick up the model aircraft to visit, avoid unnecessary losses, effectively protect the model aircraft, and effectively reduce vibration during the transportation process, avoid the model aircraft from being subjected to large vibration effects, and will not cause the internal parts of the model aircraft to loosen, effectively protect the model aircraft, Improve the service life of aircraft model.
大型飞机模型
本实用新型提供的具体技术方案如下:
The specific technical scheme provided by the utility model is as follows:
本实用新型提供的一种航模飞机用保护装置,包括安装底板和电动伸缩器,所述安装底板左侧和右侧上表面均配合连接有固定螺栓,所述安装底板上表面固定连接有防护箱,所述防护箱内部底端固定连接有减振器且减振器有多个,所述减振器顶端固定连接有固定板,所述固定板上表面固定连接有固定架,所述固定架内部固定连接有航模飞机,所述固定架左侧壁和右侧壁均固定连接有第二减振器,所述防护箱顶端配合连接有封盖,所述封盖下表面固定连接有照明灯,所述封盖右侧壁固定连接有锁紧器。
The utility model provides a protective device for aircraft model aircraft, which includes a mounting base plate and an electric telescopic device. The upper surface of the left and right sides of the mounting base plate are fitted with fixed bolts, the upper surface of the mounting base plate is fixedly connected with a protective box, the inner bottom of the protective box is fixedly connected with a first shock absorber, and there are multiple first shock absorbers, and the top of the first shock absorber is fixedly connected with a fixed plate, The upper surface of the fixed plate is fixedly connected with a fixed frame, the internal of the fixed frame is fixedly connected with an aircraft model, the left and right walls of the fixed frame are fixedly connected with a second shock absorber, the top of the protective box is connected with a cover, the lower surface of the cover is fixedly connected with a light, and the right wall of the cover is fixedly connected with a lock.
本实用新型实施例提供一种航模飞机用保护装置:
The embodiment of the utility model provides a protective device for aircraft model:
安装底板上表面固定有防护箱,通过固定螺栓将安装底板固定在展示台上,同时防护箱内部安装有固定板且固定板上表面安装有固定架,通过固定架将航模飞机固定在防护箱内部,同时防护箱顶端安装有封盖,封盖右侧固定有锁紧器,锁紧器左侧底端内部开设有安装槽,通过安装槽安装有电动伸缩器,且电动伸缩器前端固定有锁块,通过外界电源接通电动伸缩器的电源,电动伸缩器带动锁块镶嵌移动进入到防护箱的锁孔内部,通过锁紧器能将封盖稳定固定在防护箱上端,避免参观者将封盖打开,在展示过程中通过防护箱能避免参观者与航模飞机直接接触,不会发生参观者将航模拿起进行参观的现象,避免造成的不必要的损失,有效保护航模飞机。
The upper surface of the mounting base plate is fixed with a protective box, and the mounting base plate is fixed on the display platform by fixing bolts. At the same time, the inner part of the protective box is installed with a fixed plate and the upper surface of the fixed plate is installed with a fixed frame. The aircraft model is fixed in the protective box by the fixed frame. At the same time, the top end of the protective box is installed with a cover, the right side of the cover is fixed with a lock, the left bottom end of the lock is opened with an installation slot, and the electric telescopic device is installed through the installation slot, In addition, the front end of the electric telescopic device is fixed with a lock block, which is connected to the power supply of the electric telescopic device through the external power supply. The electric telescopic device drives the lock block to move into the lock hole of the protective box. The lock block can stably fix the cover on the upper end of the protective box to prevent the visitors from opening the cover. During the display process, the protective box can prevent the visitors from directly contacting the aircraft model, and the visitors will not pick up the aircraft model to visit, Avoid unnecessary losses and effectively protect the model aircraft.
固定板底端安装有多个减振器,固定架两侧也均固定有第二减振器,减振器和第二减振器均由液压杆和阻尼减震弹簧组成,在航模飞机运输过程中产生振动力,振动力会通过防护箱传递到航模飞机上,在振动力传第过程中会经过减振器和第二减振器,当振力传递来时液压杆会向下压缩并带动阻尼减震弹簧向下压缩,阻尼减震弹簧向下压缩能有效缓冲传递来的振动力,避免航模飞机受到较大的振动力效果,不会造成航模飞机内部的零件松动,有效保护航模飞机,提高航模飞机的使用寿命。更多相关内容就来我们网站http://www.quanyimoxing.com咨询吧!
Several first shock absorbers are installed at the bottom of the fixed plate, and the second shock absorbers are also fixed on both sides of the fixed frame. The first shock absorber and the second shock absorber are composed of hydraulic rods and damping damping springs, which generate vibration force during the transportation of the aircraft model. The vibration force will be transmitted to the aircraft model through the protective box, and will pass through the first shock absorber and the second shock absorber during the transmission of the vibration force, When the vibration force is transmitted, the hydraulic rod will compress downward and drive the damping spring to compress downward. The downward compression of the damping spring can effectively cushion the transmitted vibration force, avoid the aircraft model being subjected to large vibration force effect, and will not cause the internal parts of the aircraft model to loosen, effectively protect the aircraft model and improve the service life of the aircraft model. Come to our website for more relevant content http://www.quanyimoxing.com Ask!
-
