进行大型航空模型制作需绘制什么图？当然要绘制图了，比如三维图，结构图等，目的是为了更好的制作出效果，大大降低失败的几率。下面来看看：

What drawings need to be drawn for the production of large aviation models? Of course, it is necessary to draw diagrams, such as three-dimensional diagrams and structural diagrams, in order to better produce effects and greatly reduce the probability of failure. Let's take a look:

绘制三维图

Draw a three-dimensional diagram

根据上面的设计和计算结果，我们就可以绘制出自己需要的飞机了。绘制三维图的主要目的是为了得到您想要的飞机效果，并确定每个部件的形状和位置。使您在以后的工作中，有一个基本的蓝图。

According to the above design and calculation results, we can draw the plane we need. The main purpose of drawing a three-dimensional diagram is to get the desired aircraft effect and determine the shape and position of each component. So that you have a basic blueprint in your future work.

绘制结构图

Draw structure diagram

绘制结构图的主要目的是为了确定每个部件的布局和制作步骤。如：哪个部件用什么材料，先做哪个部件后作哪个部件，部件与部件的结合方法等等。

The main purpose of drawing the structure diagram is to determine the layout and manufacturing steps of each component. For example, which parts are made of what materials, which parts are made first and which parts are made later, and the combination method of parts and components.

航空模型技术常用术语：

Common terms of aviation model technology:

1、翼展——机翼(尾翼)左右翼尖间的直线距离。(穿过机身部分也计算在内)。

1. Wing span - the linear distance between the left and right wingtips of the wing (tail). (The part passing through the fuselage is also included).

2、机身全长——模型飞机很前端到很末端的直线距离。

2. Full length of fuselage - the straight-line distance from the very front to the very end of the model aircraft.

3、——模型飞机各部分重力的合力作用点称为。

3. Center of gravity - The point of action of the combined force of the gravity of each part of the model aircraft is called the center of gravity.

4、尾心臂——由到水平尾翼前缘四分之一弦长处的距离。

4. Tail center arm - the distance from the center of gravity to the quarter chord length of the leading edge of the horizontal tail.

5、翼型——机翼或尾翼的横剖面形状。

5. Airfoil - the cross section shape of a wing or tail.

6、前缘——翼型的很前端。

6. Leading edge - the very front end of the airfoil.

7、后缘——翼型的很后端。

7. Trailing edge - the very rear end of the airfoil.

8、翼弦——前后缘之间的连线。

8. Wing chord - the line between the front and rear edges.

9、展弦比——翼展与平均翼弦长度的比值。展弦比大说明机翼狭长。

9. Aspect ratio - the ratio of wingspan to average chord length. A large aspect ratio indicates that the wing is narrow and long.

放样和组装

Setting out and assembly

根据您绘制的图纸，应做一比一的装配图。目的是在组装飞机各部件时，在装配图上粘接各部件。这样能做到直观准确，提高工作质量。更多相关内容就来我们网站http://www.quanyimoxing.com咨询吧！

According to the drawings you draw, you should make a one-to-one assembly drawing. The purpose is to bond all parts on the assembly drawing when assembling all parts of the aircraft. This can be intuitive and accurate, and improve the quality of work. Come to our website for more relevant content http://www.quanyimoxing.com Ask!
