大型舰船模型的制作完成不是一件简单的事情,过程还是比较复杂且繁杂的,但是也会有问题出现,比如说模型变形了,这会是什么原因造成的呢?
It is not a simple thing to complete the production of large ship model, the process is still complicated and complicated, but there will be problems, such as model deformation, what is the cause of this?
所在地的温差,是否有暖气;;是放在展示盒内保存,还是直接放在空气中;
The temperature difference in the location, whether there is heating; Whether to store in display box or directly in the air;
是放在柜子内,还是放在卧室客厅等温差较大的位置;是否有阳光照射,还是有阳光散射到的地方,还是处于完全阴蔽;粘的PE的长度,制作前PE本身打卷情况;用胶量多少,是否粘在漆面上,如果粘在漆面上,有没有用力按压过,用的是液状502点胶,还是啫喱状502点胶。
Is placed in the cabinet, or in the bedroom living room and other large temperature difference position; Whether there is sunlight, whether there is a place where sunlight scatters, whether it is in total shade; The length of sticky PE, PE itself before production roll; How much glue is used, whether it is stuck to the paint surface, if it is stuck to the paint surface, whether it has been pressed hard, whether it is liquid glue 502 or gel glue 502.
大型舰船模型的船体是否有固定,螺丝数量和螺丝分布位置如何;注意一点对于全底铜柱固定船来说,舰首舰尾还是会存在一定程度的变形,千万不要觉得全底船不会变形,无非全底船变形看起来不明显而已,因此铜柱固定也要把两个铜柱尽量分开一点如果是树脂零件变形,底下浮空的地方是否有加强固定。
Whether the hull of large ship model is fixed, the number and distribution of screws; Note for the bottom copper column fixed ship, the ship first aft will still exist a certain degree of deformation, don't feel full bottom boat will not deformation, nothing but full bottom ship deformation looks not obvious, so the copper column fixed to separate the two copper bar as far as possible a bit if it is resin parts deformation, if there is a strengthening fixed bottom down space.
PE过长导致热胀冷缩崩开,这里千万记得一点,哪怕是塑料船,PE也是不能用太长的,像栏杆这种PE都要裁开,如果是树脂则要求裁的更短。锚甲板也尽量换成胶板来制作,这样甲板和锚甲板材质相同,粘在一起时才不容易因为热胀冷缩原因崩开,不要用原件的长条PE。
PE too long lead to thermal expansion and cold collapse, here do remember a little, even if it is a plastic ship, PE is not too long, like the rail PE to cut, if it is a resin is required to cut shorter. Anchor deck should also be made by plastic board as far as possible, so that the deck and anchor deck have the same material and are not easy to collapse due to thermal expansion and cold contraction when they stick together. Do not use the original PE strip.
树脂常见问题的话,就在底下镂空/浮空的树脂零件要注意内部填充或者钢筋支撑,不然就可能发生不同程度的变形,轻则凹陷,重则扭曲。
If the resin common problem, in the bottom hollow/floating resin parts should pay attention to internal filling or reinforcement support, otherwise it may occur different degrees of deformation, light depression, heavy distortion.
If the completed model has deformation (including hull deformation, strip PE deformation, parts falling off, resin parts deformation, etc.), do not know how to solve the problem, you can come to the website www.quanyimoxing.com consultation.
